ADVANCE ADAPTERS INC.

P/N: 716131-V

P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447

PAGE 1 OF 4

Telephone: (800) 350-2223

Fax: (805) 238-4201

Page Rev. Date:

07-25-12

KIT NO.

716131-V

CONSISTS OF:

No.

Qty.

Part No.

Description

JEEP 727 & 999 TORQUEFLITE TO CHEVY

GEN III ENGINES (REPLACING AMC 6 CYL.)

Torqueflite 999

GENERAL INFORMATION

GENERAL INFORMATION

GENERAL INFORMATION

GENERAL INFORMATION

GENERAL INFORMATION

JEEP 727 & 999 TORQUEFLITE:

This adapter plate is designed for exclusive use on AMC Torqueflite transmissions manufactured from 1980 & up. The
transmission being used must have been previously installed with a 6 cylinder engine. Vehicles that were previously
equipped with a 4 cylinder engine or 2.8 V6 will not be able to use this adapter.
Jeep used some 727 transmissions
between 1973 through 1979, but without modifications. This kit is not compatible with these transmissions. This kit
will work on both the larger 727 transmissions and the smaller 999 & 904 transmissions. It will be the customer's
responsibility to make any necessary adjustments required for the torque converter spacing. We have included a torque
converter spacer and crank support bushing that will fit most applications.

IN ORDER TO AVOID TRANSMISSION

DAMAGE, THE CUSTOMER MUST VERIFY THE CORRECT CONVERTER LOCATION.

The difference between the 727 and the 999 transmissions is in the size of the bolts that hold the converter to the
flexplate. We have provided 3/8"-24 NF bolts for the 999 transmissions 1980-1991, 5/16"-24 NF for the 727
transmission, and 8mm-1.0 bolts for 1992 & newer 999 transmissions. These bolts must be used with flat washers
and thread retainer.

INSTALLATION PROCEDURES

INSTALLATION PROCEDURES

INSTALLATION PROCEDURES

INSTALLATION PROCEDURES

INSTALLATION PROCEDURES

1. The torque converter must first be installed into the transmission assembly. Make sure the notches on the converter

line up with the drive notches in the transmission. Install the converter to the maximum depth or position inside
transmission. The torque converter must be installed onto the transmission making sure that both sets of splines
are properly engaged. We recommend that you take a measurement of the stock AMC flexplate in reference to the
stock AMC block

(see photos)

. This measurement should be approximately 1/2".

1.

1

711500A4

MODIFIED FLEXPLATE FOR TH400 ONLY

2.

1

712548-PLT

DUST COVER PLATE

3.

1

716131

ADAPTER PLATE

4.

2

716131-DP

SPECIAL DOWEL PINS FOR AMC TRANS TO ADAPTER RING

5.

1

716131-TR

TORQUE CONVERTER ADAPTER RING

6.

6

716141A

GEN III FLEXPLATE BOLT (flexplate to engine, through spacer)

7.

1

716155A

CRANK SPACER

8.

3

720028

HEX HEAD BOLT 10mm x 1.5 x 35mm LONG (GM block bolts)

9.

3

720038

10mm LOCK WASHER (GM block bolts)

10.

2

720050

10mm HEX NUT(into GM block)

11.

4

720060

8MM-1.0 X 25MM HHCS

12.

2

720061

10mm ALL-THREAD (into GM block)

13.

4

723136

5/16-24 X 1" HHCS

14.

7

723704

3/8" LOCK WASHER (transmission bolts)

15.

2

723720

H.H.C.S. 3/8"-16 x 3/4" LONG (transmission bolts)

16.

5

723744

HEX HEAD CAP SCREW 3/8"-16 x 2-1/4" (transmission bolts)

17.

4

723735

FLAT WASHER FOR TORQUE CONVERTER BOLTS

18.

3

723758

HEX HEAD CAP SCREW 3/8"-16 x 3/4"(FLEXPLATE BOLTS)

19.

4

723760

3/8-24 X 1" HHCS

20.

1

JP001

JEEP INSTRUCTION MANUAL

SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components.
We recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are
normally available at automotive dealerships and parts stores.
