3. Specifications
The Snor kel MHP15/44 is a boom sup ported el e vat ing work plat form built to con form to these stan dards,
Amer
i can Stan dard ANSI A92.2-2001, Ca na dian Stan dard C225-00 2002., Aus tra lian Stan dard
AS1418-10(Int) 2004 El e vating Work Plat forms.
NOTE:
For fur ther de tails re gard ing lu bri cants, main te nance sched ules and ser vice please re fer to the Main te -
nance and Re pair Parts Man ual for this ma chine.
■ General Specifications
SPECIFICATIONS MHP15/44
Working height 15.4m 50'
Platform height 13.4m 44'
Rated load 227kg 500lb
Rated load (with rotator) 200kg 440lb
Platform size 1.2 x 0.7 x 1.14m 4' x 2’ 6” x 3’ 7”
Platform construction Steel
Platform levelling Mechanical
Boom type Articulating
Horizontal reach 6.45m at 8m 21' 1" at 26' 3"
Maximum wind speed 12.5m/s 45kph 28mph
Turntable rotation 540 O non-continuous or 360 O continuous
Power source (std.) Gasoline engine 5.5hp
Hydraulic system Proportional electro/hydraulic
Stabilisation 4 independently operated hydraulic outriggers with safety
interlocks
Stabiliser footprint (max.) 3.7 x 3.6m 12' 1" x 13' 9"
Standard colour Snorkel orange base and covers, white turret and booms
Transport height 2.1m 6' 10"
Overall length 7.45m 24' 5"
Overall width - outriggers extended 3.7m 12' 1"
Overall width - outriggers stowed 1.77m 5' 9"
Tyre size 165 x 13LT
Brakes Hydraulic disc
Maximum towing speed 80kph 50mph
Maximum rated axle capacity 2000kg 4409lb
Weight (standard model) 1500kg 3306lb
Insulation rating Nil
Trailer tongue weight 90kg 198lb
MHP15/44 – 12459A page 3 - 1
