5
Steering
1. Push the steering switch RIGHT or LEFT to turn
the wheels. Observe the tires while maneuvering
to insure proper direction.
Note: Steering is not self-centering. Wheels must
be returned to the straight ahead position by
operating the steering switch.
Raising and Lowering the Platform
1. Position the drive/lift switch to LIFT.
2. While holding the control lever so the interlock
lever is depressed, push the control lever slowly
to UP to raise the platform. Pushing the control
lever farther increases the lift speed.
3. When the work task is completed, position the
drive/lift switch to LIFT and lower the platform by
pulling back on the control lever until the platform
is fully lowered.
Travel with Work Platform Elevated
Travel with platform elevated ONLY on firm and level
surfaces.
Note: The work platform will travel at reduced
speed when in the elevated position.
1. Check that the route is clear of persons, obstruc-
tions, holes and drop-offs, is level and capable of
supporting the wheel loads.
2. Check clearances above, below and to the sides
of platform.
3. Position the drive/lift switch to the DRIVE posi-
tion.
4. Push the control lever to FORWARD or
REVERSE for the desired direction of travel.
If the machine quits driving and the tilt alarm
sounds, immediately lower the platform and
move the machine to a level location before re-
elevating the platform.
Operation
Before operating work platform, ensure that the pre-
operation and safety inspection has been completed,
any deficiencies have been corrected and the opera-
tor has been thoroughly trained on this machine.
Travel With Platform Lowered
1. Verify chassis emergency stop switch is in the
ON position (turn counterclockwise), the drive
enable indicator is on, and that the platform/
chassis switch is on PLATFORM.
Note: If the drive enable indicator is off, verify
that the platform is fully lowered.
2. After mounting platform, secure the chain (close
and latch gate on Euro machines). Check that
guardrails are in position and properly assembled
with fasteners properly torqued.
3. Check that route is clear of persons, obstruc-
tions, holes and drop-offs and is capable of
supporting the wheel loads.
4. Check clearances above, below and to the sides
of the platform.
5. Pull controller emergency stop button out to ON
position.
6. Turn controller key switch fully clockwise to start
engine, releasing the key once the engine starts.
Note: If the engine is cold, on dual fuel models,
depress and hold the choke button in while
starting the engine. On diesel models, depress
and hold the glow plug button for 6 seconds to
engage the glow plugs.
7. Set the drive speed range switch to;
2-wheel drive – HIGH TORQUE
4-wheel drive – Middle Position.
8. Grasp the control lever so the interlock lever is
depressed (releasing the interlock lever cuts
power to controller). Slowly push or pull the
control lever to FORWARD or REVERSE to
travel in the desired direction. The farther you
push or pull the control lever from center the
faster the machine will travel.
9. While moving, push the speed range switch to
HIGH SPEED for travel on level surfaces or to
HIGH TORQUE for climbing grades or traveling
in confined areas.
10. On 4-wheel drive machines, use HIGH
TORQUE position for steep grades or muddy
conditions where more torque is required. STOP WHEN TILT
ALARM SOUNDS
WARNING: If tilt alarm
sounds, lower platform and
drive to a level surface.
