Introduction
060570-028 MX15 / MX19 - Operation Manual Page 3
I
NTRODUCTION
This manual covers the application of the MX Series Self-Propelled Work Platforms. This manual must be
stored on the machine at all times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G ENERAL D ESCRIPTION
W A R N I N G ! !
DO NOT use the maintenance platform without guardrails properly assembled and in place.
Figure 1: MX Series
1. Platform
Controls
2. Manual Case
3. Deck Extension
4. Platform
5. Elevating
Assembly
6. Chassis
7. Batteries
8. Charger Outlet
Plug
9. Chassis
Controls
10. Emergency
Lowering Valve
Knob
11. Hydraulic Fluid
Reservoir
2
1
3
4
5
7
6
8
9
10
11
10
11
Front
