060570-028 MX15 / MX19 - Operation Manual
Specifications
S
PECIFICATIONS
*Specifications are subject to change without notice. Hot weather or heavy use may affect performance.
Refer to the Service Manual for complete parts and service information.
The MX15/19 meets or exceeds all applicable CE machinery directive requirements.
ITEM
MX15
MX19
Platform Size (Inside minimum)
Standard w/Deck
0,72 m x 2,5 m (28.5 in. x 100 in.)
0,72 m x 2,5 m (28.5 in. x 100 in.)
Maximum Platform Capacity
Standard w/Deck Extension
250 kg (550 lbs.)
227 kg (500 lbs.)
Maximum Number of Occupants
Standard w/Deck Extension
2 People indoors/1 person outdoors
2 People indoors/1 person outdoors
on Extension
1 Person
1 Person
Height
Working Height
6,57 m (21 ft. 7 in.)
7,8 m (25 ft. 6 in.)
Maximum Platform Height
4,57 m (15 ft.)
5,8 m (19 ft.)
Maximum Drivable Height
4,57 m (15 ft.)
5,8 m (19 ft.)
Dimensions
Weight
1284 kg (2830 lbs.)
1406 kg (3100 lbs.)
Overall Width
760 mm (30 in.)
760 mm (30 in.)
Overall Height (Lowered)
1,89 m (74.5 in.)
2,01 m (79.25 in.)
Overall Length (Deck in)
1,75 m (68.75 in.)
1,75 m (68.75 in.)
Drive Speed
Platform Lowered
3,7 km/h (2.3 mph)
3,7 km/h (2.3 mph)
Platform Raised
1,0 km/h (0.62 mph)
1,0 km/h (0.62 mph)
Energy Source
24 V battery pack (4-220 A hour, 6 V
batteries, min. wt. 26,3 kg [58 lbs.]
each), 4 HP DC electric motor
24 V battery pack (4-220 A hour, 6 V
batteries, min. wt. 26,3 kg [58 lbs.]
each), 4 HP DC electric motor
System Voltage
24 V DC
24 V DC
Battery Charger
20 A, 110/220 VAC
20 A, 110/220 VAC
Hydraulic Reservoir Capacity
12,9 L (3.4 US gal.)
12,9 L (3.4 US gal.)
Maximum Hydraulic System Pressure
207 bar (3000 psi)
207 bar (3000 psi)
Hydraulic Fluid
Normal above 0° C [32° F]
ISO #46
ISO #46
Low Temp. below 0° C [32° F]
ISO #32
ISO #32
below -17° C [0° F]
ISO #15
ISO #15
Lift System
One Single Stage Lift Cylinder
One Single Stage Lift Cylinder
Drive Control
Motor Control
Motor Control
Control System
Control Handle with Interlock Switch,
Rotary Drive/Lift Switch, and Red
Mushroom Emergency Stop Switch
Control Handle with Interlock Switch,
Rotary Drive/Lift Switch, and Red
Mushroom Emergency Stop Switch
Drive System
Dual Front Wheel Hydraulic Motors
Dual Front Wheel Hydraulic Motors
Tires
30,5 cm (12 in.) diameter solid rubber,
Non-marking
30,5 cm (12 in.) diameter solid rubber,
Non-marking
Parking Brake
Dual, Spring Applied, Hydraulic Release
Dual, Spring Applied, Hydraulic Release
Turning Radius (inside)
150 mm (6 in.) Inside
150 mm (6 in.) Inside
Maximum Gradeability
29% (16°)
29% (16°)
Wheel Base
1,23 m (48.5 in.)
1,23 m (48.5 in.)
Guardrails
1,10 m (43 in.)
1,10 m (43 in.)
Toeboard
150 mm (6 in.)
150 mm (6 in.)
Noise Level
