Page 9
Winch Parts List
NO .
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
Part#
300100
300200
300300
300001
300002
300003
300004
300400
300005
300006
300007
300008
300009
300010
300011
300012
300500
300013
300014
300015
300016
300017
300018
300019
300020
300021
300022
300023
300022
300033
300035
300036
300045
S.B part#
97203-01
97203-02
97203-03
97203-04
97203-05
97203-06
97203-07
97203-08
97203-09
97203-10
97203-11
97203-12
97203-13
97203-14
97203-15
97203-16
97203-17
97203-18
97203-19
97203-20
97203-21
97203-22
97203-23
97203-24
97203-25
97203-26
97203-27
97203-28
97203-29
97203-30
97203-31
97203-32
97203-33
QTY
1
1
1
1
1
1
1
2
2
1
2
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Description
Motor
gasket
bearing
bearing bushing
brake base
brake gear
drum support motor side
drum bushing
tie rod
bushing for water proof
o-ring for water proof
drum
spring
Split snap ring
shaft
gear box cover
Gasket
splined gear
Gear carrier assembly state 3
Gear carrier assembly state 2
Gear carrier assembly state 1
sun gear
gasket
Slide block for clutch
gear ring
gear box body
bushing
clutch knob
Wire rope and hook
Remote
Handle Bar Control
Winch Plate
Solenoid
-17-
-18-
XRC 3.0 3,0001b Winch
Part # 97203
WWW.SMITTYBILT.COM
XRC 3.0 3,0001b Winch
Part # 97203
WWW.SMITTYBILT.COM
XRC 3.0 (3,000lb) WINCH
Line Pull
lbs 0
1000
20
00
3000
kg 0
454
9
07
1361
Line Speed
ft/min 24.5
14.7
10
.5
6.9
m/min 7.5
4.5
3.2
2.1
Mo tor
Amps
15
75
1 20
175
Specifications
Rated line pull. 3000lbs (1360kgs) single line
Motor. Permanent magnetic DC 12V with 3.9hp/2.9kw out put
Gear train. 3 stage planetary
Gear ratio. 136:1
Wire rope. 7/32``
32'
Drum size. 50mm
75mm
Dimensions. L
W
H (334mm
114mm
120mm)
N.W. 7.5 kg
G.W. 11 k g
