Installation Instructions
Replacement Top (Part # 987xx)
86-94 Suzuki Sidekick/Geo Tracker
Step 7: Locate the straps on the side of the top near the center sports bar. Pull them forward and slide
through the loops on the end of tension assembly located near the base of the front header
bar. (Fig H) Pull strap back and snap together.
Step 8:
Locate the flap with snaps in the center of the top. This folds over and snaps to the center sport
bar around the down light. (Fig I) Note: The strap is used to secure the windshield header when
you have it folded back.
(Fig I) (Fig J)
Step 9:
Push the side windows back towards the vehicle and latching the retainer bar into the factory
bracket located on the vehicle. Secure inside with retainer bar strap also. (Fig J, K)
(Fig K) (Fig L)
