Smittybilt 987xx Replacement Top - Manual

WWW.SMITTYBILT.COM
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
Replacement Top (Part # 987xx)
86-94 Suzuki Sidekick/Geo Tracker
Step 1:
Remove OEM top (if equipped). Remove the top skin only, not the bow assembly. Fold the front
header back. (Fig A) Remove the fiberglass rod in the rear window for later use.
Step 2:
Attach the rear window to top. Drape the new top over the vehicle and bow assembly. (Fig B)
(Fig A) (Fig B)
Step 3:
Slide the front of the top over front header. (Fig C) Hook the five clips into the slots on the bottom
of the header. Its easier to clip the middle three first and then the ones on each side. (Fig D)
(Fig C) (Fig D)
Note: Please read instructions entirely before installing this product.
