Installation Instructions
Rugged Rack
Part # 17185
(Figure 1) (Figure 2)
Step 3: Push the front upright into the side upright. (Figure 4) Do this step at all four corners.
Note: It may be necessary to use a rubber mallet to carefully tap parts together.
(Figure 3) (Figure 4)
Step 4: Lay the floor flat slats out over the cross members. Align the holes in the floor slats with the
holes on the cross members. (Figure 5)
Step 5: Attach the floor slats to the cross members using the screws provided. (Figure 6)
