Installation Instructions
Bull Bar (#53037&53038)
09-On Dodge Ram
Fig 5
Measure from the mounting point
for the splash guard to the
bracket on the driver and
passenger sides. Use this
measurement as a reference point
to check location before cutting
the 1/2" wide x 4" long slot
Fig 7
If required, replace the
rivet with the supplied:
6mm x 20mm Button
Head Allen Bolts
6mm Flat Washers
6mm Nylock Hex Nuts
Hole for mounting bolt
(Fig 8A) Driver side Support
Bracket in "no Tow Hook" position
Cut only what is needed to insert bracket
through the splash guard. Do not cut
through the front edge of the splash guard
Fig 6
