Installation instructions – Smittybilt 17290 Bolt-On Fender Flares User Manual
Page 4
WWW.SMITTYBILT.COM
For Technical Support/Warranty Information please call 310-762-9944
Smittybilt, 400 West Artesia Blvd, Compton, CA 90220
Installation Instructions
Bolt-On Fender Flares
Chevy Silverado 1500,2500,3500
(07-13)
Part #17290
STEP 12:
Double check the front and rear Fender Flares
to make sure all bolts are tight and clips are securely
fastened. Your installation is now complete. Do not use
abrasive cleaners.
STEP 11:
To secure the Fender Flare to the body, take the
black metal clips and slide them over the Fender Flare and
the inner wheel arch lip. Position the clip so that the barb in
the clip locates in the slot of the Fender Flare. Ensure all
fixing points are secure and that the rubber seal is flush
neatly against the body.
