42
11.4 Connecting rods
Device type 1830/1030 2800/1500
Item number 840720571 840720575
Length(retracted)
[mm] 1030 1500
[in.] 40.6 59.1
Length(extended)
[mm] 1830 2800
[in.] 72.1 110
Dimensions
(diameter)
[mm] 65 50
[in.] 2.6 2
Weight
[kg] 40 58.5
[lbs.] 88 129
Device type 1.1 m / 184 mm 2.2 m / 184 mm
Item number 840726381 840726382
Dimensions
(L x B x H)
[mm] 1100 x 350 x 184 2200 x 350 x 184
[in.] 43.3 x 13.8 x 7.24 86.6 x 13.8 x 7.2
Weight
[kg] 70 140.5
[lbs.] 154 310
Device type 3.3 m / 184 mm 4.4 m / 184 mm
Item number 840726383 840726384
Dimensions
(L x B x H)
[mm] 3300 x 350 x 184 4400 x 350 x 184
[in.] 130 x 13.8 x 7.24 17.3 x 13.8 x 7.24
Weight
[kg] 211 281
[lbs.] 465 620
