11.2 Rolling carriage
Device type RC-700/350 RC-1000/350
Item number 840720640 840721631
Dimensions
(L x B x H)
[mm] 390 x 380 x 130 360 x 380 x 154
[in.] 15.4 x 15 x 5.12 14.2 x 15 x 5.5
max. width of
rerailing bridge
[mm] 350 350
[in.] 13.8 13.8
max. permitted
load
[kN] 750 1000
[lbf.] 168600 224800
Weight
[kg] 41.5 62
[lbs.] 91.7 139
11.3 Rerailing bridges
Device type 1.1 m / 85 mm 2.2 m / 85 mm 3.3 m / 85 mm
Item number 840726391 840725792 840725093
Dimensions
(L x B x H)
[mm] 1100 x 350 x 85 2200 x 350 x 85 3300 x 350 x 85
[in.] 43.3 x 13.8 x 3.35 86.6 x 13.8 x 3.35 130 x 13.8 x 3.35
Weight
[kg] 34 68 102
[lbs.] 75 15 225
Device type 1.1 m / 140 mm 2.2 m / 140 mm
Item number 840726350 840725750
Dimensions
(L x B x H)
[mm] 1100 x 350 x 140 2200 x 350 x 140
[in.] 43.3 x 13.8 x 5.5 86.6 x 13.8 x 5.5
Weight
[kg] 40 80
[lbs.] 88 176
Device type 3.3 m / 140 mm 4.4 m / 140 mm
Item number 840725050 840726550
Dimensions
(L x B x H)
[mm] 3300 x 350 x 140 4400 x 350 x 140
[in.] 130 x 13.8 x 5.51 173 x 13.8 x 55.1
Weight
[kg] 120 160
[lbs.] 265 353
