40

Chapter 2

Installing or Replacing Components

3

Loosen the two captive screws that secure the riser bracket to the back panel and

gently pull the bracket and riser straight up and out of the slot.

Captive screws

4

Remove the screw on the riser bracket, and then remove the port access cover.
