1 Make sure that both the Macintosh and the video equipment
are turned off.
2 Attach one end of the video cable to the video out port on
the video equipment.
3 Plug the other end of the video cable into the S-video input
port on the video input card.
About the S-video port: The S-video port accepts 4-pin and
7-pin connectors.
If the connector doesn’t slide easily into the port, realign it
and try again. Avoid using force, which could damage the
card or the connector.
4 Insert the RCA plugs on one end of the audio cables into the
left and right audio out ports on the video equipment.
If you’re using a Y-adapter audio cable: Plug the single
end of the cable into the audio out port on your video
equipment.
5 Insert the RCA plugs on the other end of the audio cables
into the left (white) and right (red) sound input ports on the
video input card.
Be sure to plug the cable from the left audio out port on
the video equipment to the left sound input port on the
computer. Connect the right ports in the same way.
If you’re using a Y-adapter cable: Plug the double end of
it (where it forms a Y) into the right and left sound input
ports on the video input card.
