4 Examine the nozzle test pattern for broken or missing diagonal lines.
The nozzle test pattern appears near the bottom of the test page. The test
pattern for the color ink cartridge looks like this:
The test pattern for the black ink cartridge looks like this:
5 If you see a broken line, one or more nozzles may be clogged. See the section “Cleaning
the Print Head” in Chapter 5.
What’s next?
You’re now ready to start using your printer.
m If you want to share the printer with others on your network, see “Using
ColorShare to Share Your Printer With Other Users” and “Printing on a
Shared Color StyleWriter 1500” in Chapter 2. If you purchased the optional
EtherTalk Adapter for this printer, see “Connecting a Color StyleWriter
1500 to an EtherTalk Network” in Chapter 2.
m If you have installed QuickDraw GX and turned it on, see Appendix E.
Yellow
Magenta
A broken line means a nozzle on
the print head needs to be cleaned. A missing color means you
need to replace the ink cartridge.
Cyan
22 Chapter 1
