Wire Reference Table
Possible Wires
What They Control
R or V or VR
RH
and RC Single power for HEAT and COOL
RH or 4
RH
Power for HEAT (RH not connected to RC jumper wire removed)
RC
RC
Power for COOL (RH not connected to RC jumper wire removed)
W
W
Heat control
W2
W2
2nd stage HEAT
AUX or AUX1
AUX1
1st stage of AUX heat in the CT100
AUX2
AUX2
2nd stage of AUX heat in the CT100
Y
Y
COOL control or 1st stage compression for heat pump
Y2
Y2
2nd stage COOL control or 2nd stage compression for a heat pump
G or F
G
FAN control
C or X
C
24VAC power (to power thermostat)
NOTE: TRANE, AMERICAN STANDARD and YORK often use the letter B for C
H
H
External Humidiier
DH
DH
External Dehumidiier
EX
EX
external fresh air bafle
B
B
Heat pump changeover (cool to heat, powered in heat)
O
O
Heat pump changeover (heat to cool, powered in cool)
B and O
IMPORTANT: If there are both B and O wires (Trane pump
products) DO NOT CONNECT B to B terminal, connect B to C
terminal.
E
n/a Emergency heat (do not connect, tape off)
L
n/a System monitor (do not connect, tape off)
T
n/a Outdoor sensor (do not connect, tape off)
