AEM 30-6311 Series 2 Plug & Play EMS User Manual
Page 9
Page 9 of 12
91-93 94-97
91-93 3000 GT
94-97 3000 GT
AEM EMS 30-6311
I/O
91-93 Notes
94-97 Notes
101
31
Ignition OK input
Fuel Pump Relay (Low)
Not Used
---
---
---
102
32
Active Exhaust*
Wastegate Solenoid*
PW 2
Output PnP for Wastegate Control Solenoid
<--
103
33
Active Exhaust Switch
---
Not Used
---
---
---
104
34
Timing Adjust Connector
Active Exh / LF O2 Heater
Injector 12
Output Avail, Inj output 1.5A max (not P&H)
<--
105
35
Wastegate Solenoid*
RF O2 Heater*
PW 2
Output PnP for Wastegate Control Solenoid
<--
106
36
Check Engine
<---
Low Side 10
Output
PnP for 7,000 RPM Shift Light
<--
107
37
PS Press. Switch
<---
Switch 5
Input Avail, switch must connect to ground
<--
108
38
MFI Relay Control
<---
Main Relay (Coil7) Output Dedicated, switched GND to relay
<--
109
39
---
Boost Gauge (96-97)
Low Side 1
Output
Avail, Switched Ground driver
<--
110
40
---
Fuel Pressure Sol (96-97)
---
---
---
---
111
41
Boost Gauge
Boost Gauge (94-95)
EGT4 (ADCR16)
Input
Avail, jumper set for 0-5V Input
<--
112
42
Data Link Connector
LR O2 Heater (96-97)
EGT3 (ADCR15)
Input
Avail, jumper set for 0-5V Input
<--
113
43
Data Link Connector
RR O2 Heater (96-97)
High Side 4
Output
Avail, Switched 12v, 1.5A max
<--
114
44
ABS Control
<---
Switch 6
Input Avail, switch must connect to ground
<--
115
45
Magnetic Clutch
<---
Switch 2
Input
PnP for A/C request switch
<--
116
46
---
---
Injector 7
Output Avail, Inj output 1.5A max (not P&H)
<--
91-93 94-97
91-93 3000 GT
94-97 3000 GT
AEM EMS 30-6311
I/O
91-93 Notes
94-97 Notes
80
51
---
---
Low Side 3
Output Avail, Switched Ground, 1.5A max
<--
81
52
---
Ign. Timing Adj
Coil 3
Output
PnP for Coil 3, rising edge trigger
(connects to pin 11)
<--
82
53
---
---
Coil 5
Output
Avail, 0-5V rising edge trigger
<--
83
54
---
---
Injector 9
Output Avail, Inj output 1.5A max (not P&H)
<--
84
55
---
---
Low Side 5
Output Avail, Switched Ground, 1.5A max
<--
85
56
---
Data Link Connector
Coil 6
Output
Avail, 0-5V rising edge trigger
<--
86
57
---
---
Idle 7
Output
Avail, Ground / +12V, 1.5A max
<--
87
58
---
Ignition OK input
Not Used
---
---
---
88
59
---
A/C clutch slip input
Low Side 12
Output Avail, Switched Ground, 1.5A max
<--
89
60
---
Right O2 Sensor Rear (Cal)
Injector 11
Output Avail, Inj output 1.5A max (not P&H)
<--
90
61
---
---
EGT2
Input
Avail, jumper set for 0-5V Input
<--
91
62
---
Data Link Connector
Coil 4
Output
Avail, 0-5V rising edge trigger
<--
