Connection Diagram for EMS P/N 30-6051
PnP
Means the Plug and Play system comes with this configured for proper operation of this
device. Is still available for reassignment by the end user.
Available
Means the function is not currently allocated and is available for use
Dedicated
Means the location is fixed and cannot be changed
Pin
1999-2002 Honda Accord V6 J30A1;
2002-2004 Honda Odyssey 3.5L V6 J35A4
1999-2003 Acura 3.2 TL/CL V6 J32A1;
2002-2003 Acura 3.2 TL/CL V6 Type S J32A2;
AEM EMS
30-6051
I/O
Notes
A1
Engine Coolant Temp (ECT) Gauge (1999 Honda Accord V6
J30A1);
MTRTW serial signal (2000-2002 Honda Accord V6 J30A1);
Secondary heated O2 sensor
---
---
Not used
A2
Engine mount control solenoid
←
Low side 1
Output
Available, switched ground, 1.5A max
A3
EVAP bypass solenoid valve
←
Low side 3
Output
Available, switched ground, 1.5A max (set
as reverse lockout in calibration)
A4
EVAP control canister vent shut
←
Low side 5
Output
Available, switched ground, 1.5A max
A5
Cruise control signal
← EGT
1
Input
Available, jumper set for 0-5V input
A6
EVAP purge control solenoid
←
Low Side 4 Output
Available, switched ground, 1.5A max
A7
Reference voltage (2001-2002 Accord V6 J30A1 only)
Reference voltage (1999 Acura CL V6 J30A);
Unterminated (2000-2003 Acura TL/CL V6 J32A1);
Serial Data Line (2002-2003 Acura TL/CL V6 Type S J32A2)
Sensor
+5V
Output
Dedicated, +5V sensor power output
A8
Secondary O2 heater control
←
Low side
12
Output
Available, switched ground, 1.5A max
A9
Vehicle speed output
←
Speedo
freq signal
Output
PnP for speedometer signal to dashboard
A10
Service check signal
← Injector
12
Output
Available, switched ground, 1.5A max
A11
A/T range switch (2001-2002 Accord V6 J30A1 only)
---
PW 3
Output
Available, PWM switched ground, 1.5A
max
A12
Immobilizer indicator light
---
Injector 9
Output
Available, switched ground, 1.5A max
A13
Immobilizer enable signal (1999-2000 Honda Accord V6 J30A1
only);
SVC intake manifold runner control (2002-2003 Acura TL/CL
V6 Type S J32A2 only)
Coil 7
Output
Available, 0/5V falling edge signal
A14
D4 indicator light (A/T)
D5 indicator light (A/T)
Injector 11
Output
Available, switched ground, 1.5A max
A15
Fuel pump relay
←
Low side
11
Output
PnP for fuel pump relay (connected to Pin
A16)
A16
Immobilizer enable signal (2001-2002 Honda Accord V6 J30A1
only);
---
Low side
11
Output
Available, fuel pump relay (connected to
Pin A15)
Wire View of AEM EMS
