Infinity Pin Hrdwr Ref. Hardware Specification Notes
C1-13 Coil 2_Out 25 mA max source current 0-5V Falling edge fire. DO NOT connect directly to
coil primary. Must use an ignitor OR CDI that
accepts a FALLING edge fire signal.
C1-14 Coil 1_Out 25 mA max source current 0-5V Falling edge fire. DO NOT connect directly to
coil primary. Must use an ignitor OR CDI that
accepts a FALLING edge fire signal.
C1-15 Coil 6_Out 25 mA max source current 0-5V Falling edge fire. DO NOT connect directly to
coil primary. Must use an ignitor OR CDI that
accepts a FALLING edge fire signal.
C1-16 Coil 5_Out 25 mA max source current 0-5V Falling edge fire. DO NOT connect directly to
coil primary. Must use an ignitor OR CDI that
accepts a FALLING edge fire signal.
C1-17 LowsideSwitch_2_Out Lowside switch, 4A max, NO
internal flyback diode.
No pullup
See Setup Wizard Pages "User GPOs" for activation
criteria and "LowSide Assignment Tables" for
output assignment
C1-18 LowsideSwitch_3_Out Lowside switch, 4A max with
internal flyback diode. Inductive
load should NOT have full time
power.
No pullup
Normally used as MIL output. 'See Wizard page
"LowSide Assignment Tables" for output
assignment.
C1-19 AGND_1_Out Dedicated analog ground Analog 0-5V sensor ground
C1-20 AGND_1_Out Dedicated analog ground Analog 0-5V sensor ground
C1-21 Crankshaft Position
Sensor Hall_In 10K pullup to 12V. Will work with
ground or floating switches. See Setup Wizard page Cam/Crank for options.
C1-22 Camshaft Position
Sensor 1 Hall_In 10K pullup to 12V. Will work with
ground or floating switches. See Setup Wizard page Cam/Crank for options.
C1-23 Digital_In_2 10K pullup to 12V. Will work with
ground or floating switches. See Setup Wizard page Cam/Crank for options.
C1-24 Digital_In_3 10K pullup to 12V. Will work with
ground or floating switches. See Setup Wizard page Turbo Speed for calibration
constant.
