- 5 -
To assemble:
Reverse the procedure in the first five steps above.
The Rotor and Body are very closely fit and must be properly aligned to reassemble.
DO NOT FORCE IT OR IRREPAIRABLE DAMAGE WILL OCCUR.
To Operate and Adjust:
Attach the Mounting Bracket to your bench or shelf using (2) #14 Binding
Head Sheet Metal Screws or other suitable hardware. The screws should be
approximately _" back from the edge of the bench, and the smaller of the
two large holes should be suspended off of the bench.
Place the Powder Measure in the hole of the Mounting Plate, thread the Lock
Ring onto the Powder Measure, tighten the Lock Ring to the Mounting Plate
and lock it in place with the 3/32" hex wrench, if desired.
Select the appropriate Drop Tube (The smaller for 20 and 25 caliber, the
larger for 6.5 mm and up) and thread it into the bottom of the Powder Mea-
sure until it is secure against the internal shoulder. (Finger tight is all that is
required.)
