- 4 -

Your Powder Measure has been treated with a rust preventative which

must be

removed before use. We recommend that you clean and degrease all metal parts with
Hornady One-Shot Cleaner and Dry Lube.

To Disassemble:

Set the Rotor with the Metering Unit perpendicular to the axis of the Body,

press the Push Button and hold it down while removing the Metering Unit.
NOTE: Do NOT remove push button. It is permanently installed and does not
need cleaning.

Remove the Handle, or Rotating Arm from the Powder Measure, by removing

the two attaching screws with a 1/8" hex wrench.

Slide the Rotor out of the Body by pressing gently on the handle side of the

Rotor.

Be careful not to drop or otherwise damage the Rotor while it is out of

the Body.

Remove the Lock Nut, O-Ring and Sleeve from the Metering Plunger. Spray all

metal parts liberally with Hornady One Shot-Gun Cleaner and Dry Lube. Be
sure all rust preventatives are removed.

Allow it to dry thoroughly before reassembling.
