- 10 -

Step 1: Assembling the Case Activated Powder Drop Rotor Arm

Reinstall the Rotor with the handle side to the right (metering opening facing you).

Place the Metering Unit back into the Rotor.

Attach the Case Activated Powder Drop Rotor Arm (#3) to the right side of the Rotor

using two Button Head Cap Screws (#4).

Fig. 1: Attaching the
Case Activated Powder
Drop Rotor Arm.

L-N-L POWDER MEASURE
