GrimmSpeed IWG Bracket User Manual
Page 2
G
rimm
s
peed
2
3. Place GrimmSpeed IWG Bracket in same location as where the OEM wastegate
was. LOOSELY install the 2-3 bolts that hold the Bracket to the turbo. If you do
not loosely install all bolts before tightening down you may have install issues.
4. Reinstall bolt or C-Clip on wastegate door arm.
5. Now you may TIGHTEN 2-3 bolts that bolt Bracket to turbo.
Please contact us if you have any questions during installation.
Thank you for your purchase!
