34. Torque (5) 14mm nuts from EWG up pipe to turbo.
35. Install EWG Dump Tube to Wastegate via V-Band Clamp. You may need to use
pliers to tightly close V-Band Clamp.
36. Install wastegate to EWG up pipe side outlet flange via V-Band Clamp.
37. Remove OEM Internal wastegate from turbo.
38. Install Internal Wastegate Bracket to keep internal wastegate door shut(if
applicable).
39. Reinstall passenger side exhaust manifold collector o2 bung.
40. Reinstall downpipe.
41. Reinstall plastic splash guard.
42. Reinstall turbo heatshield.
43. Reinstall intercooler and BOV.
NOTE: It is highly recommended to install an aftermarket boost controller when using an
EWG setup.
NOTE: The V-Band Clamps will be tight. It may be necessary to use a pliers to fully close
the V-Band Clamps prior to putting the bolt in.
Please contact us if you have any questions during installation.
Thank you for your purchase!
