ARB 3520030 - Manual (Page 3)

Last Rev Date: 18/07/11 Page 3 of 15 Fitting instructions# 3787968
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
Fitting Kit 6172343 PARTS LISTING
APPLICATION. PART NO. QTY DESCRIPTION
Mount Assembly To Chassis
3756848
3756851R
3756851L
3193741
6151306
6151255
6151189
6151094
4581049
4581050
5846401
1
1
1
2
2
8
6
2
18
10
4
Bracket Mount Assembly
Bracket Mount Brace RHS
Bracket Mount Brace LHS
Captive Nut Plate
Nut Cage M12 x 1.75
Bolt M12 x 1.75 x 40mm
Nut M12 x 1.75
Bolt M12 x 1.25 x 30mm
Washer Flat M12
Washer Spring M12
Spacer 8mm
Bull Bar To Impact Absorber
6151357
4581040
6151026 10
10
10 SEMS Bolt M10 x 1.5 x 30mm
Washer Flat M10 x 2mm
Nut M10 x 1.5
Indicators To Bull Bar
3163015
6821152
6821151L
6821151R
1
2
1
1 Combination Light Surround Kit
Turn signal / clearance light loom
Turn Signal / Clearance Light
Turn Signal / Clearance Light
Winch To Bull Bar
EG50
3756499
6151021
4581044
6151132
BLB560
4581040
6151074
1
1
2
2
2
2
4
2 Rubber Grommet
Bracket Control Box
Bolt M8 x 20mm
Washer Flat M8
Nut Flange M8
Cable Black 560mm
Washer Flat 3/8” x 1”
Bolt 1 ¾” x 3/8” UNC
Number Plate To Bull Bar
6821189
6151384
6781408 2
2
1 Grommet Nylon Nut
Screw Pan Hd Phil 5x16mm
Tape Double sided
Miscellaneous
6821132
180302
3162152
3756857
2
8
2
1 Rubber Grommet 3/8” ID
Cable Ties
Plastic Plug 16mm DIA
Bracket Bracing Lower Grille
Supplementary Kit:
3520010 06-09 Models:
Stone Tray
6542088
6151300
6151213
4584310
4581287 1
4
4
4
4 Stone Tray 06-09
Nut Cage 6mm
Bolt M6 x 20mm BZ
Washer Flat M6 BZ
Washer Spring M6 BZ
Supplementary Kit:
3520020 2010 ON Models:
Stone Tray and Wing Under Panels
6542111
6522795 R&L
6151300
6151213
4584310
4581082
4581287
6151132
6151234
4581307
4581047
3787825
1
1 pr
14
16
6
10
16
2
2
4
2
1
Stone Tray 2010 ON
Wing under panels
Nut Cage 6mm
Bolt M6 x 20mm BZ
Washer Flat M6 THK BZ
Washer Flat M6 BZ
Washer Spring M6 BZ
Nut Flange 8mm
Bolt M8 x 25mm BZ
Washer Flat Panel M8 BZ
Washer Spring M8 BZ
Template drilling mount holes
