FITTING REQUIREMENTS
REQUIRED TOOLS FOR FITMENT OF PRODUCT:
Basic Tool Kit
External Circlip pliers
17mm Tube Spanner
Power Drill 13mm capacity
7mm, 10mm and 13mm drill bits
Cold chisel
HAVE AVAILABLE THESE SAFETY ITEMS WHEN FITTING PRODUCT
:
Protective eyewear
Hearing protection
NOTE: ‘WARNING’ notes in the fitting procedure relate to OHS situations, where to avoid a
potentially hazardous situation it is suggested that protective safety gear be worn or a safe work
procedure be employed. If these notes and warnings are not heeded, injury may result.
FASTENER TORQUE SETTINGS:
SIZE
Torque Nm
Torque lbft
M6 9Nm
7lbft
M8 22Nm
16lbft
M10 44Nm
32lbft
M12 77Nm
57lbft
OPTIONAL LIGHT SETS TO SUIT THIS PRODUCT:
♦ ARB 6821201 Fog Light Kit Suit 3163015
♦ Up to IPF 900 SERIES FOG OR DRIVING LIGHT SETS
