Removal of bumper – ARB 3415010 User Manual
Page 7
Last Rev Date:29/10/2008
Page 7 of 20
Fitting instructions# 3783250
Copyright © 2005 by ARB Corporation Limited. All rights reserved, this document must not be reproduced without the express authority of ARB Corporation Ltd
REMOVAL OF BUMPER
14. Remove screws located along top of cross
member retaining upper bumper metal frame.
Removal of bumper.
15. Pull outward and slightly forward on bumper
cover in upper wheel arch area to unclip tab
on bumper cover from retaining bracket on
fender. The bumper and cover should now
be released. Carefully remove bumper and
set aside.
Hint: This operation is best performed with two
people, one on each end of the bumper.
16. Remove plastic plugs in cross member.
17. Remove cross member and set aside.
