ARB 3415010 User Manual

Page 3

Last Rev Date:29/10/2008

Page 3 of 20

Fitting instructions# 3783250

APPLICATION. PART

NO.

QTY DESCRIPTION

Mount Brackets To Chassis

3756991R

3756991L

6151428
6151429
6151396
5846400

1
1
2
2
2
2

Bracket Mount RHS
Bracket Mount LHS
Flange Nut M12
Chassis Stud M12 x 265 x 1.75
Nut Clevis
Packer M12 x 8mm

Brace Assembly

4681241
6151357
6151321

1
7
7

Brace
SEMS Bolt M10 x 1.5 x 30mm
Nut Flanged M10 x 1.5

Bull Bar To Mount Bracket Assy

6151357
6151321
6151255
6151189
4581049
4581050

2
2
6
6

SEMS Bolt M10 x 1.5 x 30mm
Nut Flanged M10 x 1.5
Bolt M12 x 1.75 x 40mm
Nut M12 x 1.75
Washer Flat M12
Washer Spring M12

Stone Tray to Bull Bar

6522671
6151303
6151022
4581063
4581046

1
6
6

Stone Tray
Nut Cage 8mm
Bolt M8 x 25mm
Washer Flat M8 x25.4 x 3
Washer Spring M8

Indicators To Bull Bar

6821151R

6821151L

6151308
6821116
6821152

180701
180302

6821192

1
1
4
4
2
6
4
2

Indicator Assembly RH
Indicator Assembly LH
Screw Self Tapping
Nut Nylon Plug
Loom
Scotch Locks
Cable Tie
Bulb 12V 10W BA15S

Winch To Bull Bar

3756775
3199790
6151364
4581291
6151321

180302

1
1
2
2
2
8

Bracket Control Box Univ.
Plate Trim for 16500LB Control Box
Screw Cap M10 x 30
Washer Flat M10 BZ
Nut M10 Flanged
Cable Tie

Winch Hole Cover Fitment

(If Not Fitting Winch)

6151128
6151256
6522048
6191013
6151046

2
2
1
1
2

Nut Flange M6
Screw M6 St/Stl Button Head
Extrusion Winch Cover
Panel Winch Cover
Washer M6

Number Plate To Bull Bar

6151017
6151046
6151128
3751384

4
4
4
1

Bolt M6 x 16
Washer M6
Nut M6 Flanged
Bracket Number Plate

Fog Lamps

3757029
6151300
6151017
6151046
4581036
4581306
3162457
3162456

2
6
6
6
6
2
1
1

Adapter Bracket
Nut Caged M6
Bolt M6 X 16
Washer M6
Washer Spring M6
Washer
Light Aperture Molding RH
Light Aperture Molding LH

Miscellaneous

6151128
6151213
4581082

2
2
4

Nut Flanged M6
Bolt M6 X 20 BZ
Washer Flat M6 X 20 BZ
