11. Device Network TX CAN messages

11.1. Software version message (ES-Key designation 0x9A to 0xFF)

Priority: 6

Datapage:

0

PDU Format:

239

PDU Specific:

255

Source addr:

154

Message frequency: 10 per second


Byte 5 – Software version

(high nibble = major rev, low nibble = minor rev)


11.2. Output States message (ES-Key designation 0x9A to 0x9B)

Priority: 6

Datapage:

0

PDU Format:

239

PDU Specific:

30

Source addr:

154

Message frequency: 10 per second

Byte 0 – Load 1 through Load 8 state

(Load 0 is in the LSb position)

Byte 1 – Load 9 through Load 16 state

(Load 9 is in the LSb position)

Byte 2 – System Voltage

(Low Byte)

Byte 3 – System Voltage

(High Byte)

Byte 4 – Iso Battery Voltage

(Low Byte)

Byte 5 – Iso Battery Voltage

(High Byte)

Byte 6 – User Set Point

(Low Byte)

Byte 7 – User Set Point

(High Byte)


11.3. Input States message (ES-Key designation 0x9A to 0x9C)

Priority: 6

Datapage:

0

PDU Format:

239

PDU Specific:

30

Source addr:

154

Message frequency: 10 per second

Byte 0 – Master Switch state

(0x00 OFF 0x01 ON)

Byte 1 – Park Brake Switch state

(0x00 OFF 0x01 ON)

Byte 2 – Load Manage Switch state

(0x00 OFF 0x01 ON)

Byte 3 – System Voltage Mode

(0x00 12 volt system 0x01 24 volt system)

Byte 4 – Override State

(0x00 OFF 0x01 ON)

Byte 5 – Fast Mode

(0x00 OFF 0x01 ON) used for factory testing

Byte 6 – 0x00
Byte 7 – 0x00
