5. Programming

Example

5.1. Programming

Example

You want load #3 to shed at a voltage level of 12.0 volts. It needs to be tied to the Master Switch and be activated in
the Scene Mode.

1. Depress

the

USER and PROG switches until (---) is displayed.

2. Press

the

NEXT switch until L03 is displayed on the digital display.

3. Press

the

MODE switch until only the SCENE LED is on.

4. Press

the

ACTIVE switch until only the WRM MASTER LED is on.

5. Press

the

PRIORITY switch until P04 is displayed on the digital display.

6. Press

the

STORE switch until 3 dashes (---) are displayed on the digital display.

7. If you want to configure another output select the NEXT switch and repeat the procedure to program that

output.

8. When all the outputs are programmed press and hold PROG switch until Pro is displayed on the digital

display.


Note: If you do not press the STORE switch after each Output is configured that Output will not be changed.

6. Connector

Information

6.1. Terminal Function and Polarity

Terminal Function

Polarity

Terminal Function

Polarity

1 Load

Manage

Enable

POS/GND

13

Output Load # 1

POS/GND

2

Output Load # 2

POS/GND

14

Output Load # 3

POS/GND

3

Output Load # 4

POS/GND

15

Output Load # 5

POS/GND

4

Output Load # 6

POS/GND

16

Output Load # 7

POS/GND

5

Output Load # 8

POS/GND

17

Output Load # 9

POS/GND

6

Output Load # 10

POS/GND

18

Output Load # 11

POS/GND

7

Output Load # 12

POS/GND

19

VAR Trip Output

POS/GND

8

AUX Battery Alarm

POS/GND

20

Output Fast Idle

POS/GND

9

Low Voltage Alarm

POS/GND

21

Parking Brake Input

POS/GND

10

Master Switch Input

POS/GND 22 CAN

LOW

N/A

11 CAN

HIGH

N/A

23 Aux

Battery Input

Positive

12

Main Battery Power

Positive

24

Ground

Ground


Mating connector

AMP 770587-1

Socket(Loose Form)

AMP 171639-1

16-18 Ga

Socket(Strip form)

AMP 171637-1

16-18 Ga

Crimping Tool

AMP 90760-1

Pro Crimper

Contact Extraction Tool

AMP 189727-1

Connector and Socket Kit

Class1 P.N. 101536

Mating Pigtail

Class1 P.N. 101538


The Main battery power (term #12) and ground (term #24) should be wired direct to the battery as possible.
