S

emi-Automatic

P

riming

V

alve

8

Figure 6. Universal Mounting Adapter

Dimensions

3-

7

/

8

IN.

(98 mm)

2-

1

/

4

IN.

(57 mm)

3-

3

/

4

IN.

(95 mm)

2-

1

/

2

IN.

(64 mm)

Figure 7. Universal Mounting Adapter Mounting Positions

NOTE: STUDS MUST BE INSTALLED IN HOLES THAT LIE ON THE

HORIZONTAL CENTERLINE OF THE UNIVERSAL ADAPTER.

The Universal Mounting Adapter can be mounted to a secure point on

the apparatus with the attaching holes (flat portion) located in the down

position or as shown below.

to the apparatus.

5. Apply a light coat of thread locking

compound (Loctite #290 or equal) to
one end of the

7

/

16

-14 x 1-

3

/

4

inch long

studs. Install the studs in horizontal holes
on the universal adapter. Refer to figure
8.

6. Insert strainer and seal ring in universal

adapter then install Hale SPV on the
universal adapter over the studs. Make

Hale SPV Installation with Universal
Mounting Adapter:

When installing the Hale SPV assembly with
a universal mounting adapter use the
following procedures.

1. Place the apparatus out of service in

accordance with departmental
procedures.

CAUTION: Make sure the Hale SPV is
located higher than the pump body
allowing water to drain from the
vacuum hose.

2. Determine location of Hale SPV Universal

Mounting adapter on the apparatus.
When choosing location of universal
mounting adapter make sure there is
minimum of 5 inches (127 mm)
clearance for hose connections.

3. Refering to the dimensions in figure 6,

drill two

29

/

64

inch (12 mm) holes 2-

1

/

2

inches (64 mm) apart to attach the
universal mounting adapter to a secure
point on the apparatus.

4. Select the proper mounting adapter

orientation (refer to figure 6 and 7) and
using

7

/

16

-14 x 1 inch long cap screws

attach the universal mounting adapter
