PARTS LIST HALE TYPE K HEAT EXCHANGER
FIGURE 6-10
ITEM NO. PART NO
QTY DESCRIPTION
1
018-1406-02-0
8
Screw – 5/16-18 X 3/4 Lg. Cad. Pl. Stl. Hex Cap
2
018-1412-02-0
1
Screw – 5/16-18 X 1-1/4 Lg. Cad. Pl. Stl. Hex Cap
3
044-0670-00-0
1
Header – Heat Exchanger
4
046-5970-00-0
1
Gasket – Header
5
046-5980-00-0
2
Gasket – Connector
6
048-0510-00-0
2
Sleeve – 5/16 In. O.D. Tubing
7
082-3004-00-0
2
Connector-1/4 In. NPT Female x 5/16 O.D. Tube
8
108-0180-00-0
1
Body – Heat Exchanger
9
115-0800-01-0
*
Connector – 1-1/4 "B" Cooler
115-0800-02-0
*
Connector – 1-1/2 "C" Cooler
115-0800-03-0
*
Connector – 1-3/4 "D" Cooler
115-0800-04-0
*
Connector – 2 "E" Cooler
115-0800-05-0
*
Connector – 2-1/4 "F" Cooler
115-0800-06-0
*
Connector – 2-1/2 "G" Cooler
10
217-0201-00-0
1
Plug – 1/4 NPT M.I.
11
507-0150-00-0
1
Coil – Heat Exchanger Cooler
*NOTE: (2) CONNECTORS REQUIRED PER ASSEMBLY IN ANY COMBINATION
