75.5185.04 20070727 Page 7 of 8
7
Manual Setup
If a remote control is not available, only the sensitivity parameter can be adjusted manually, by means of the push
buttons + (Plus) and - (Minus).
The sensor parameters that are not accessible manually will remain at the factory preset values.
Pressing the two push buttons located on the circuit board, simultaneously for at least two seconds, will
restore all default values except the lock code. Previously set lock codes will be retained.
+ Press to increase
sensitivity by one unit.
- Press to decrease
sensitivity by one unit.
Immunity
Immunity helps to reduce the chance of
unwanted detections due to environmental
disturbances.
1 = Reduced
2 = Normal
3 = Increased
4 through 9: enhanced immunity (for highly
reflective environment)
Default: 2
Relay Hold Time
Relay hold time refers to the hold time on the
output relay of the Eagle. Values range from 0 to
9.
0 = .5 sec.
1 = 1 sec through 9 = 9 sec in 1 second intervals
Default: 0
Detection Mode
Detection mode offers 3 different levels of
detection:
1 = Bi-Directional
2 = Uni-Directional
3 = Uni-Directional with motion tracking feature
Default: 3
Sensitivity
0 = Minimum Sensitivity
9 = Maximum Sensitivity
Default: 8
* Every adjustment, when using the infrared remote control, must start with the unlocking function, and end with the
locking function.
