ACCESSORY DIMENSIONS
Roof Curb — 580D036-072
ROOF CURB
ACCESSORY
‘‘A’’
UNIT SIZE
580D
CRRFCURB001A00
1
Ј
-2
Љ
[356]
036-072
CRRFCURB002A00
2
Ј
-0
Љ
[610]
NOTES:
1. Roof curb accessory is shipped unassembled.
2. Insulated panels.
3. Dimensions in [
] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest on
curb).
6. Service clearance 4 ft on each side.
7.
Direction of airflow.
UNIT SIZE
580D
‘‘B’’
‘‘C’’
‘‘D’’ ALT
DRAIN
HOLE
‘‘E’’
GAS
POWER
CONTROL
CONNECTOR
PKG ACY
036-072
1
Ј
-9
11
⁄
16
Љ
[551]
1
Ј
-4
Љ
[406]
1
3
⁄
4
Љ
[45]
3
⁄
4
Љ
NPT
3
⁄
4
Љ
NPT
1
⁄
2
Љ
NPT
CRBTMPWR001A00*
(Thru-The-Bottom)
3
⁄
4
Љ
NPT
1
1
⁄
4
Љ
NPT
1
⁄
2
Љ
NPT
CRBTMPWR002A00*
(Thru-The-Bottom)
*Either connector package available for either roof curb.
