Bryant 580D User Manual
Page 19
BASE UNIT DIMENSIONS — 579F180,216
UNIT
579F
DIMENSIONS
X
Y
Z
ft-in.
mm
ft-in.
mm
ft-in.
mm
180
3-2
965
4-0
1219
1-10
559
216
3-7
1090
3-2
965
1- 8
508
UNIT
579F
CORNER WEIGHT*
A
B
C
D
lb
kg
Lb
kg
lb
kg
lb
kg
180
384
174
370
168
358
162
538
244
216
520
235
508
230
486
220
636
288
*Weights are for unit only (aluminum plate fins) and do not in-
clude options or crating.
NOTES:
1. Dimensions in (
) are in millimeters.
2.
Center of gravity.
3.
Direction of airflow.
4. Ductwork to be attached to accessory roof curb or adapter only.
5. Minimum clearance:
a. Rear: 7
Ј
0
Љ
(2134) for coil removal. This dimension can be re-
duced to 4
Ј
0
Љ
(1219) if conditions permit coil removal from
the top.
b. Left side: 4
Ј
0
Љ
(1219) for proper condenser coil airflow.
c. Front: 4
Ј
0
Љ
(1219) for control box access.
d. Right side: 4
Ј
0
Љ
(1219) for proper operation of damper and
power exhaust (if so equipped).
e. Top: 6
Ј
0
Љ
(1829) to assure proper condenser fan operation.
f. Local codes or jurisdiction may prevail.
6. With the exception of clearance for the condenser coil and the
damper/power exhaust as stated in Note No. 5, a removable
fence or barricade requires no clearance.
7. Dimensions are from outside of corner post. Allow 0
Ј
-
5
⁄
16
Љ
(8) on
each side for top panel drip edge.
8. Do not locate adjacent units with flue discharge facing econo-
mizer inlet.
19
