Table 2B — Electrical Data (Units Without Convenience Outlet) (558F091, 103, 121, 151)
LEGEND
*Used to determine minimum disconnect per NEC.
†Fuse or HACR circuit breaker per NEC.
**Fuse only.
††Compressor no. 1 is shown in table.
208/230-3-60: Compressor no. 2 RLA is 14.1 amps and LRA is 105 amps.
460-3-60: Compressor no. 2 RLA is 7.1 amps and LRA is 55 amps.
575-3-60: Compressor no. 2 RLA is 6.4 amps and LRA is 40 amps.
NOTES:
1.
In compliance with NEC requirements for multimotor and combination load equipment (refer to NEC
Articles 430 and 440), the overcurrent protective device for the unit shall be fuse or HACR breaker.
Canadian units may be fuse or circuit breaker.
2.
Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply voltage is greater than 2%. Use the
following formula to determine the percent of voltage imbalance.
% Voltage Imbalance
Example: Supply voltage is 460-3-60.
AB = 452 v
BC = 464 v
AC = 455 v
= 457
Determine maximum deviation from average voltage.
(AB) 457 – 452 = 5 v
(BC) 464 – 457 = 7 v
(AC) 457 – 455 = 2 v
Maximum deviation is 7 v.
Determine percent of voltage imbalance.
= 1.53%
This amount of phase imbalance is satisfactory as it is below the maximum allowable 2%.
IMPORTANT: If the supply voltage phase imbalance is more than 2%, contact your local electric utility
company immediately.
3. For units with power exhaust: If a single power source is to be used, size wire to include power
exhaust MCA and MOCP. Check MCA and MOCP when power exhaust is powered through the
unit (must be in accordance with NEC and/or local codes). Determine the new MCA including the
power exhaust using the following formula:
MCA New = MCA unit only + MCA of Power Exhaust
For example, using a 558FPX091000 unit with MCA = 40.1 and MOCP = 45, with
CRPWREXH030A01 power exhaust.
MCA New = 40.1 amps + 1.6 amps = 41.7 amps
If the new MCA does not exceed the published MOCP, then MOCP would not change. The MOCP
in this example is 45 amps, the MCA New is below 45, therefore the MOCP is acceptable. If “MCA
New” is larger than the published MOCP, raise the MOCP to the next larger size. For separate
power, the MOCP for the power exhaust will be 15 amps per NEC.
4. Determine heater capacity using multiplication factors table below:
NOTE: The following equation converts kW of heat energy to Btuh: kW x 3.412 = Btuh.
EXAMPLE: 32.0 kW (at 240 v) heater on 208 v
= 32.0 (.751 mult factor)
= 24.0 kW capacity at 208 v
558F
UNIT
SIZE
NOMINAL
V-PH-Hz
IFM
TYPE
VOLTAGE
RANGE
COMPRESSOR
(ea)
OFM (ea)
IFM
FLA
HEATER
MODEL NO.
CRHEATER---A00
ELECTRIC HEAT
POWER SUPPLY
DISCONNECT
SIZE*
SINGLE POINT
BOX P/N
CRSINGLE---A00
Min
Max
Qty
RLA
LRA
Qty
Hp
FLA
Nominal
kW
FLA
MCA
MOCP†
FLA
LRA
091
208/230-3-60
STD
187
254
2
14
91
2
1
/
4
1.4
5.8
NONE
—/—
—/—
40.1/ 40.1
45/ 45
42/ 42
229/229
—
017
7.8/10.4
21.7/ 25.0
40.1/ 40.1
45/ 45
42/ 42
229/229
006
010
12.0/16.0
33.4/ 38.5
48.9/ 55.4
50/ 60
45/ 51
229/229
006
011
18.4/24.8
51.7/ 59.7
71.9/ 81.8
80/ 90**
66/ 75
229/229
007
012
24.0/32.0
66.7/ 77.0
90.6/103.5 100/110**
83/ 95
229/229
007
012 and 017
31.8/42.4
88.4/102.0
117.7/134.8 125/150**
108/124
229/229
009
ALT
5.8
NONE
—/—
—/—
40.1/ 40.1
45/ 45
42/ 42
229/229
—
017
7.8/10.4
21.7/ 25.0
40.1/ 40.1
45/ 45
42/ 42
229/229
006
010
12.0/16.0
33.4/ 38.5
48.9/ 55.4
50/ 60
45/ 51
229/229
006
011
18.6/24.8
51.7/ 59.7
71.9/ 81.8
80/ 90**
66/ 75
229/229
006
012
24.0/32.0
66.7/ 77.0
90.6/103.5 100/110**
83/ 95
229/229
007
012 and 017
31.8/42.4
88.4/102.0
117.7/134.8 125/150**
108/124
229/229
009
HIGH
10.6
NONE
—/—
—/—
44.9/ 44.9
50/ 50
48/ 48
273/273
—
017
7.8/10.4
21.7/ 25.0
44.9/ 44.9
50/ 50
48/ 48
273/273
006
010
12.0/16.0
33.4/ 38.5
54.9/ 61.4
60/ 70**
51/ 56
273/273
007
011
18.6/24.8
51.7/ 59.7
77.9/ 87.8
80/ 90**
72/ 81
273/273
007
012
24.0/32.0
66.7/ 77.0
96.6/109.5 100/110**
89/101
273/273
007
012 and 017
32.3/42.4
88.4/102.0
123.7/140.8 125/150**
114/129
273/273
009
460-3-60
STD
414
508
2
6.4
42
2
1
/
4
0.7
2.6
NONE
—
—
18.4
20
19
108
—
016
13.9
16.7
24.1
25
22
108
006
013
16.5
19.8
28.1
30
26
108
006
014
27.8
33.4
45.0
50
41
108
006
015
33.0
39.7
52.9
60
49
108
006
014 and 016
41.7
50.2
65.9
70**
61
108
008
ALT
2.6
NONE
—
—
18.4
20
19
108
—
016
13.9
16.7
24.1
25
22
108
006
013
16.5
19.8
28.1
30
26
108
006
014
27.8
33.4
45.0
50
41
108
006
015
33.0
39.7
52.9
60
49
108
006
014 and 016
41.7
50.2
65.9
70**
61
108
008
HIGH
4.8
NONE
—
—
20.6
25
22
130
—
016
13.9
16.7
26.9
30
25
130
006
013
16.5
19.8
30.8
35
28
130
006
014
27.8
33.4
47.8
50
44
130
006
015
33.0
39.7
55.6
60
51
130
006
014 and 016
41.7
50.2
68.7
70**
63
110
008
575-3-60
STD
518
632
2
5.2
39
2
1
/
4
0.7
2.6
NONE
—
—
14.9
20
16
97
—
018
17.0
17.1
23.9
25
22
97
006
019
34.0
34.1
45.3
40
42
97
006
ALT
2.6
NONE
—
—
14.9
20
16
97
—
018
17.0
17.1
23.9
25
22
97
006
019
34.0
34.1
45.3
40
42
97
006
HIGH
4.8
NONE
—
—
16.7
20
18
114
—
018
17.0
17.1
26.1
30
24
114
006
019
34.0
34.1
47.5
45
44
114
006
FLA
—
Full Load Amps
HACR
—
Heating, Air Conditioning and Refrigeration
IFM
—
Indoor (Evaporator) Fan Motor
LRA
—
Locked Rotor Amps
MCA
—
Minimum Circuit Amps
MOCP
—
Maximum Overcurrent Protection
NEC
—
National Electrical Code
OFM
—
Outdoor (Condenser) Fan Motor
RLA
—
Rated Load Amps
= 100 x
max voltage deviation from average voltage
average voltage
Average Voltage =
452 + 464 + 455
3
=
1371
3
% Voltage Imbalance = 100 x
7
457
POWER EXHAUST
PART NO.
MCA
(230 v)
MCA
(460 v)
MCA
(575 v)
MOCP
(for separate
power source)
CRPWREXH021A01
N/A
0.9
N/A
15
CRPWREXH022A01
3.3
N/A
1.32
15
CRPWREXH023A01
N/A
1.8
N/A
15
CRPWREXH028A01
1.7
N/A
0.68
15
CRPWREXH029A01
N/A
1.0
N/A
15
CRPWREXH030A01
1.6
N/A
0.64
15
HEATER
RATING
VOLTAGE
ACTUAL HEATER VOLTAGE
200
208
230
240
380
440
460
480
550
575
600
240
0.694 0.751
0.918 1.000
—
—
—
—
—
—
—
480
—
—
—
—
0.626 0.840 0.918
1.000
—
—
—
600
—
—
—
—
—
—
—
—
0.840
0.918 1.000
