CARE AND MAINTENANCE
Ap
pe
ndi
x
211
8
i
Insert the bobbin case so that the projection
on the bobbin case aligns with the spring.
a Projection
b Spring
j
Insert the tabs on the needle plate cover
into the needle plate, and then slide the
cover back on.
Note
• Never use a bobbin case that is scratched;
otherwise, the upper thread may become
tangled, the needle may break, or sewing
performance may suffer. For a new bobbin
case (part code: XC3153-051 (green screw),
XC8167-051 (pink screw)), contact your
nearest authorized service center.
• Be sure that the bobbin case is correctly
installed. Otherwise, the needle may break.
b
a
a
b
