ATTACHING THE EMBROIDERY FRAME
Embr
oi
de
ry
143
5
ATTACHING THE EMBROIDERY FRAME
a
Press the “Presser Foot Lifter” button to
raise the presser foot.
b
Align the embroidery frame guide with the
right edge of the embroidery frame holder.
a Embroidery frame holder
b Embroidery frame guide
c
Slide the embroidery frame into the holder,
making sure to align the embroidery frame’s
with the holder’s .
a Arrow mark
d
Lower the frame-securing lever to be level
with the frame to secure the embroidery
frame in the embroidery frame holder.
a Frame-securing lever
■ Removing the Embroidery Frame
a
Raise the frame-securing lever.
b
Pull the embroidery frame toward you.
Note
Wind and insert the bobbin before attaching the embroidery frame.
a
b
a
CAUTION
• If the frame-securing lever is not lowered, the
embroidery pattern may not sew out correctly
or the presser foot may strike the embroidery
frame and cause injury.
a
