CARE AND MAINTENANCE
210
CARE AND MAINTENANCE
Cleaning the LCD Screen
If the screen is dirty, gently wipe it with a soft, dry
cloth. Do not use organic solvents or detergents.
Cleaning the Machine Casing
If the surface of the machine is dirty, lightly soak a
cloth in a neutral detergent, squeeze it out firmly,
and then wipe the surface. Then wipe again with a
dry cloth.
Cleaning the Race
If dust or bits of dirt collect in the race or bobbin
case, the machine will not run well, and the
bobbin thread detection function may not operate.
Keep the machine clean for best results.
a
Press the “Needle Position” button to raise
the needle.
b
Lower the presser foot.
c
Turn the main power to OFF.
d
Remove the needle and the presser foot
holder (see pages 33 through 34).
e
Remove the flat bed attachment or the
embroidery unit if either is attached.
f
Grasp both sides of the needle plate cover,
and then slide it toward you.
a Needle plate cover
→ The needle plate cover is removed.
g
Grasp the bobbin case, and then pull it out.
a Bobbin case
h
Use the cleaning brush or a vacuum cleaner
to remove any lint and dust from the race
and its surrounding area.
* Do not apply oil to the bobbin case.
a Cleaning brush
b Race
CAUTION
• Be sure to unplug the machine before cleaning it. Otherwise, electric shock or injury may result.
a
a
a
b
