SERVICE (cont.)
ELECTRONIC CONTROL ASSEMBLY (cont.)
O N CAUTION !
Failure To Comply Voids Warranty!
Hot W
ater System
s – W ater Tank W
ill Fill
Automatically W
hen Unit Is Connected To Power!
Coffee Brewers –
Fill The Water Tank In
Accordance W
ith The Installation Instructions!
DO NO
T Turn O
n The Tank H
eater Sw
itch
Until W
ater C
om
es From
O pened Faucet!
HAZARDOUS
VOLTAGE
DISCONNECT FROM
POWER SOURCE
BEFORE REMOVING!
W AR
NIN
G
#7 BLU from Triac Assy
#6 WHI/BRN to Tank Heater Switch
#5 PNK to Liquid Level Probe
#4 RED to Terminal Block (Red Insert))
#2 GRN to Ground
#1 WHI/BLU to Solenoid
TAN from Triac Assy
to Tank Heater Switch
#3 BLK to RED Lead from Liquid Level Switch
OFF N
O N
CAUTION
!
Failure To Comply Voids Warranty!
Hot W
ater System
s – Water Tank W
ill Fill
Automatically W
hen Unit Is C
onnected To Power!
Coffee Brew
ers –
Fill The W
ater Tank In
Accordance W
ith The Installation Instructions!
DO
NO
T Turn O
n The Tan
k Heater Switch
Until W
ater Com
es From
O pened Faucet!
HAZARDOUS
VOLTAGE
DISCONNECT FROM
POWER SOURCE
BEFORE REMOVING!
W AR
NIN
G
ST
OP
READ NOTICE
WHI & WHI to
Temperature Sensor
PNK (Top) &
GRY (Bottom) to
Interlock Assy
GRY & GRY to
InterLock Assy
PNK (Top) &
GRY (Bottom)
from LED
O
P1
P2
P3
P4
OFF
ON
STOP
READ NOTICE
13. Check the voltage across the tank heater terminals
(5) with a voltmeter. Connect the brewer to the
power source. The indication must be:
a.) 208 volts ac for three wire 120/208 volt mod-
els and 240 volts ac for three wire 120/240 volt
models while the red indicator on the circuit
board is on or blinking.
b.) 200 to 240 volts ac for two wire 200 or 240 volt
models while the red indicator on the circuit is
on or blinking.
14. Disconnect the brewer from the power source.
If voltage was present as described, the temperature
control of the system is operating properly. Return the
new electronic control assembly (1) and temperature
sensor (8) to Bunn-O-Matic for credit.
Electronic Controls Removal and Replacement
NOTE - each electronic control assembly is calibrated
to a temperature sensor. Both components MUST be
replaced as a set.
1. Remove all wires from the electronic control as-
sembly terminals.
2. Remove the two 8-32 screws holding the elec-
tronic control assembly to the component bracket.
3. Disconnect the temperature sensor and ready
indicator wires from the left side of the electronic
control assembly board.
4. Remove the temperature sensor from the grom-
met in the tank lid.
5. Install the new temperature sensor into the grom-
met on the tank lid. Route the wires to the location
of the new electronic control assembly.
6. Attach the temperature sensor and ready indicator
wires to the electronic control assembly.
7. Fasten the new electronic control assembly to its
bracket.
8. Reconnect the wires.
9. Refer to the following illustration when reconnect-
ing the wires.
10. Review the initial set-up procedures and adjust the
control as required for the desired temperature.
Triac Assembly Removal and Replacement
NOTE - each triac installation requires the use of an
approved silicone heat sink compound. Bunn-O-
P784
Matic recommends the use of Dow Corning 340 com-
pound or equivalent. It can be purchased direct from
Bunn-O-Matic (part number M2522.0002).
1. Place the tank heater switch on the electronic
control assembly in the “OFF” position.
2. Completely drain the tank.
3. Place a stryofoam or wood block between the
center of the tank and the rear of the brewer.
4. Disconnect triac wires, white/violet from terminal
block, blue from right tank heater, blue from
electronic control and tan from tank heater switch.
5. Carefully set the brewer on its back.
6. Remove the two 2" dia hole plugs from the bottom
cover.
7. Remove the four #10-32 keps nut securing tank to
tank mounting bracket.
8. Remove the twelve #8-32 slotted head screws
securing the bottom cover.
9. Remove the bottom cover with the four feet, the
tank mounting brackets, triac/heat sink as an
assembly.
27124 050800
