47
2.048Mbps Wireless Modem
TECHNICAL: 0118 931 2233
2. Press Esc at any stage to return to the previous menu (if you press Esc before making any
selection, the message:
Loading cancelled, old value retained appears).
Note: You can operate all the Setup and Configuration sub-menus by using these procedures
and by following the instructions on the screens.
LIU Parameters Menu
The LIU Parameters menu gives you access to the following sub-menus:
• E1 Parameters Menu (select if an E1 LIU is used).
• Fractional E1 Parameters Menu (select if a Fractional E1 LIU is used).
• T1 Parameters Menu (select if an T1 LIU is used).
• Fractional T1 Parameters Menu (select if a Fractional T1 LIU is used).
• V.35/RS-530/X.21 Parameters Menu. (Select if a V.35/RS-530/X.21 LIUis used).
• Loopback Mode.
• Line Interface Unit type (set at factory and should not be changed unless LIU changes).
E1 Parameters Menu
Table 3-1. E1 Parameters Menu Items and Actions
