104
2.048Mbps Wireless Modem
SALES: 0118 965 5100
Q-CTRL (future RJ-45, 8 pin, female
option)
RSSI Test point (for DVM), accuracy = ±20%.
Power
100 - 240 VAC or 18 - 72 VDC, 25 W max.
Management
Monitoring, diagnostics and configuration.
Interface - V.24/RS-232, 9 pins D Type female connector.
Access using a locally connected ASCII terminal or remotely via dial-up modem.
Remote unit management, through the wireless link.
Mechanical Specifications
Dimensions
Standard 1U half 19”
7.7” x 9.6” x 1.7” (195mm x 244mm x 44mm)
Weight
2.2 lb (1 Kg)
Environmental Specifications
Operating Temperature Operating: 0 - 55 o C (32 o - 130 o F)
Humidity:
5% to 90%, non-condensing
Standards
US:
FCC Part 15.247, UL, UL/C
Europe: CEPT T/R 10-01, ETS 300-328, CE, TUV/GS.
