106
2.048Mbps Wireless Modem
SALES: 0118 965 5100
Connectors
LNA 10
• RF IN: N-type, female
• RF OUT: N-type, male
• Signal and Power IN: not in use
• Signal and Power OUT: F-type, female
Power Inserter • To CONV: F-type, female
• To TV: F-type, female (not in use)
Power Supply
Required Voltage:
+12V to +28Vdc
Required Current:
20mA
Operating Temperature:
-2 0 °C to +5 0 °C
Dimensions:
60mm x 35mm x 25mm (2.3”x 1.3”x 1”)
Operating Environment:
•
LNA 10 outdoor/indoor
• Power Supply
indoor
•
Power Inserter indoor
∗ Technical specifications are listed as provided by the manufacturer
AL-1 Technical Specifications
Turn on voltage: 75V
Insertion loss:
0.3dB typical
DC path from input to output existing
Operating Temperature:
-5 5 °C to +7 0 °C
Dimensions:
67.5mm x 25mm x 25mm (2.7” x 1” x 1”)
Connectors:
Antenna
Port N-type, Female
Equipment
Port N-type, Female
