101
2.048Mbps Wireless Modem
TECHNICAL: 0118 931 2233
Frequency Accuracy
± 15ppm.
Noise Figure
5dB max.
Total Link Display
Controllable, between 14ms to 156ms, depending on the Data and Radio rates.
Line Interface Specifications
Data Rates (Full Duplex)
Nx64Kbps: 64, 128, … 2048kbps
N x 64Kbps: 64, 128, … 2048 Kbps.
LIU Options
T1 Interface
Data Rate:
1544 Kbps
Type:
DSX-1, meets CCITT G.703 and G.823
Connector:
RJ-45
Line Mode: Bipolar AMI or B8ZS
Impedance:
10 0Ω
E1 Interface
Data Rate:
2048 Kbps
Type:
CEPT-I, meets CCITT G.703 and G.823
Connector:
2 x BNC (unbalanced), RJ-45 (balanced)
Line Code:
HDB3 or AMI
Impedance:
7
5Ω
(unbalanced), 12
0Ω
(balanced).
