Maintenance

The transfer switch is designed to be maintenance free under

normal usage. However, inspection and maintenance checks

should be made on a regular basis. Maintenance will consist

mainly of keeping the transfer switch clean.
Visual inspections should be done at least once a month.

Access to transfer switch must not be obstructed. Keep

3 feet (92 cm) clearance around transfer switch. Check for

an accumulation of dirt, moisture and/or corrosion on and

around the enclosure, loose parts/hardware, cracks and/or

discoloration to insulation, and damaged or discolored

components.
Exercise the transfer switch at least once every three months

as described in the previous section “Testing the Automatic

Transfer Switch” unless a power outage occurs and Home

Generator System has gone through automatic sequence.

Allow generator to run for at least 30 minutes.
Contact a licensed electrical professional to inspect and clean

the inside of your transfer switch at least once a year.

Specifications

UL® 1008 Listed Transfer Switch

Model 071007
Maximum Load Current:. . . . . . . . . . . . . . . . . . . . 100 Amps
Rated AC Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . 250 Volts
Poles. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50/60 Hz
Fault Current Rating . . 22,000 RMS Symmetrical Amperes*
Supervisory Contacts Rating:
A-A Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Volt AC
B-B Terminals . . . . . . . . . . 1 Amp, 125 Volt AC, Pilot Duty
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 lbs.
* Short circuit rating is limited to the lowest capacity of any

device installed.
