1.2 Hardware Specifications
CPU: Up to Celeron-M 1GHz Ultra low-voltage version
Memory: 256/512 MB DDR on board (Default: 256 MB DDR).
Battery-backup RAM: 512 KB Battery-backup RAM
VGA/Keyboard/Mouse: DB-15 VGA Connector, PS/2 keyboard and
mouse
Serial Ports: 2 x RS-232 and 2 x RS-232/422/485 with DB-9 connectors.
Automatic RS-485 data flow control
Serial Speeds: RS-232: 50~115.2 kbps, RS-422/485: 50~921.6 kbps
LAN: Two 10/100 Base-T RJ-45 Ports
USB interface: Two USB ports, USB UHCI, Rev. 1.1 compliant
Printer port: One printer port
PC Card: One PC Card slot. Supports CardBus (Card-32) Card and
16-bit (PCMCIA 2.1/JEIDA4.2) Card.
Supports +5 V, +3.3 V and +12 V @ 120 mA working power
SSD: One internal Type I / Type II CompactFlash card slot
LEDs: Power, IDE, Alarm for RAM Backup Battery
PC/104: Two PC/104 Extension. (Optional)
HDD: HDD extension kit for installation of one standard 2.5" HDD
Anti-Shock: 20 G @ Wall mounting, IEC 68 2-27, half sine, 11 ms w/
HDD50 G @ Wall mounting, IEC 68 2-27, half sine, 11 ms w/CF
Anti-Vibration: 2 Grms w/CF @IEC 68 section 2-64, random, 5 ~ 500
Hz, 1 Oct./min, 1 hr/axis.0.5 Grms w/ HDD @ IEC 68 section 2-64,
random, 5 ~ 500 Hz, 1 Oct./min, 1 hr/axis
Power supply: 9 ~ 36 VDC
Power consumption: Max. 35 W
Operating temperature: -10~50°C (14~122°F)@ 5~85% relative
humidity.
Relative humidity: 95% @ 40°C
Weight: 1.6 kg
Chassis size (W
× L × H): 255 Ч152 Ч 50 mm (10″Ч6.0″Ч2.0″)
Software options: Windows XP Embedded, Windows 2000/XP, Windows
CE .NET V5.0
