2.8 PCMCIA: PC Card Slot
The UNO-2170 provides one PC Card slot that supports CardBus (Card-
32) cards and 16-bit (PCMCIA 2.1/JEIDA 4.2) card standards. It supports
+3.3 V, +5 V and +12 V @ 120 mA working voltage. The PC Card is
85.6 mm long by 54 mm wide (3.37" x 2.126"), use a 68-pin connector
and a removable module standardized by PCMCIA that is known as
“PCMCIA card＂.
PS: PCMCIA interrupt assignment is IRQ 9.
2.9 VGA Display Connector
The UNO-2170 provides a VGA controller (Intel 855/852 GME, supports a
single 1.5V accelerated graphics port interface) for a high resolution VGA
interface. It supports CRT Mode: 1280 x 1024 @ 32bpp (60Hz), 1024 x 768
@ 32bpp (85Hz); LCD/Simultaneous Modes: 1280 x 1024 @ 16bpp(60Hz),
1024 x 768 @16bpp(60Hz) and up to 32 MB shared memory.
The VGA interface is reserved for system testing and debugging. The
UNO-2170's JP8 is a 6-pin mini connector and CN7 is a 15-pin connector for
a VGA monitor. A VGA cable is attached to convert from a 6-pin mini
connector to standard VGA connector. You can choose one of the VGA
interfaces for system testing and debugging. Pin assignments for the VGA
display are detailed in Appendix A.9.
