Hardware functionality – B&B Electronics Celeron M Universal Network Controller with PC/104 Extension UNO-2170 User Manual
Page 13
2
2
Hardware Functionality
This chapter shows how to setup the
UNO-2170s hardware functions, including
connecting peripherals, setting switches and
indicators.
Sections include:
• Peripherals
• RS-232 Interface
• RS-232/422/485 Interface
• LAN / Ethernet Connector
• Power Connector
• PS/2 Mouse and Keyboard Connector
• USB Connector
• PCMCIA: PC Card Slot
• VGA Display Connector
• Battery Backup SRAM
• Reset Button
