A.6 Phoenix Power Connector (PWR)
Table A.7: Power connector pin assignments
Pin 10/100Base-T Signal Name
1 +9~36VDC
2 GND
A.7 PS/2 Keyboard and Mouse Connector
Table A.8: Keyboard and Mouse connector pin assignments
Pin Signal Name
1 KB DATA
2 MS DATA
3 GND
4 VCC
5 KB Clock
6 MS Clock
UNO-2170 User Manual 28
